Connectivity

Share your 3G/4G connection with up to 32 devices

Uses a SIM/UICC card to connect to the Internet

Four 10/100 Ethernet LAN ports to connect wired devices

Optional WAN port for fixed line broadband

802.11n/g/b wireless

Security Features

Industry standard WPA/WPA2 encryption to help protect wireless traffic

Firewall

Network Address Translation (NAT)

Stateful Packet Inspection (SPI)

Technical Specifications

Frequency Support

LTE Bands:

Release 10, Cat 4: Band 1/3/7/8/20 (800/900/1800/2100/2600 MHz)

Pentaband UMTS/HSPA/HSPA+/DC-HSPA+

Bands 1/2/3/5/8 (850/900/1800/1900/2100 MHz)

Quadband GSM/GPRS/EDGE

850/900/1800/1900 MHz

Data Throughput

LTE Mode

Downlink: Up to 150 Mbps

Uplink: Up to 50 Mbps

DC-HSPA Mode

Downlink: Up to 42 Mbps

Uplink: Up to 5.76 Mbps

Standards

IEEE 802.11n/g/b

IEEE 802.3i

802.3u

Wi-Fi Data Rates

Up to 300 Mbps with 802.11n clients

6/9/11/12/18/24/36/48/54 Mbps in 802.11g mode

1/2/5.5/11 Mbps in 802.11b mode

Functionality

Wireless Security

64/128-bit WEP (Wired Equivalent Privacy)

WPA & WPA2 (Wi-Fi Protected Access)

WPS (Wi-Fi Protected Setup)

Firewall

Network Address Translation (NAT)

Stateful Packet Inspection (SPI)

Advanced Features

L2TP/PPTP/IPSec VPN Passthrough

User configurable multi-WAN

DMZ (Demilitarized Zone)

Port/Application Forwarding

URL Filter

QoS engine (Quality of Service)

Scheduler

Virtual server

Two-way filtering

Physical

Device Interfaces

Four 10/100 Ethernet LAN ports

WAN (RJ-45) port

Wireless N Standard

Mini-SIM/UICC slot

Two detachable 3G/4G antennas

LED Status Indicators

Power

LAN

WLAN

4G

2G / 3G

Signal Strength

Dimensions

190 x 116 x 22.4 mm (7.43 x 4.57 x 0.88 inches)

Weight

295 g (0.65 lb)

Temperature

Operating: 0 to 40 °C (32 to 104 °F)

Storage: -10 to 70 °C (14 to 158 °F)

Humidity

Operating: 10% to 90% non-condensing

Storage: 0 to 95% non-condensing

Certifications

 CE

1 Supported frequency bands are dependent on regional variants and may not be available in all markets.

2 Data rates are theoretical. Data transfer rate depends on network capacity and signal strength.

3 Please check regional mobile operators for 4G LTE/3G mobile Internet availability.
