Hardware

Interfaces

· 10/100BASE-TX WAN port

· 4 10/100BASE-TX LAN ports

LEDs

· POWER

· STATUS

· WLAN / WPS

· INTERNET

· 4 LAN LEDs

Buttons

· POWER button to power on/power off

· RESET button to restore factory default settings

· WPS button to set up secure wireless connection and enable/disable wireless network

Antenna

· Internal omnidirectional antenna (2dBi gain)

Power connector

· Power input connector (DC)

Software

WAN connection types

· PPPoE

· IPv6 PPPoE

· PPPoE Dual Stack

· Static IP / Dynamic IP

· Static IPv6 / Dynamic IPv6

· PPPoE + Static IP / Dynamic IP

· PPTP/L2TP + Static IP

· PPTP/L2TP + Dynamic IP

Network functions

· DHCP server/relay

· DHCPv6 server (Stateful/Stateless), IPv6 prefix delegation

· DNS relay

· Support of DNSv6 AAAA records

· Dynamic DNS

· Static IP routing

· Static IPv6 routing

· IGMP Proxy

· RIP

· Support of UPnP IGD

· Support of VLAN

· Flow control

· WAN ping respond

· Support of SIP ALG

· Support of RTSP

Firewall functions

· Network Address Translation (NAT)

· Stateful Packet Inspection (SPI)

· IP filter

· IPv6 filter

· MAC filter

· URL filter

· DMZ

· Prevention of ARP and DDoS attacks

· Virtual servers

· Built-in Yandex.DNS web content filtering service

VPN

· IPSec/PPTP/L2TP/PPPoE pass-through

Software

Management

· Local and remote access to settings through TELNET/WEB (HTTP/HTTPS)

· Multilingual web-based interface for configuration and management

· Notification on connection problems and auto redirect to settings

· Firmware update via web-based interface

· Automatic notification on new firmware version

· Saving/restoring configuration to/from file

· Support of remote logging

· Automatic synchronization of system time with NTP server and manual time/date setup

· Ping utility

· Traceroute utility

· TR-069 client

Wireless Module Parameters

Standards

· IEEE 802.11b/g/n

Frequency range

· 2400 ~ 2483.5MHz

Wireless connection security

· WEP

· WPA/WPA2 (Personal/Enterprise)

· МАС filter

· WPS (PBC/PIN)

Advanced functions

· Support of client mode

· WMM (Wi-Fi QoS)

· Managing connected stations

· Advanced settings

Wireless connection rate

· IEEE 802.11b: 1, 2, 5.5, and 11Mbps

· IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, and 54Mbps

· IEEE 802.11n: from 6.5 to 150Mbps (from MCS0 to MCS7)

Physical Parameters

Dimensions

· 134 x 83 x 98 mm (5.3 x 3.3 x 3.9 in)

Weight

· 202 g (0.45 lb)

Operating Environment

Power

· Output: 12V DC, 0.5A

Temperature

· Operating: from 0 to 40 °C

· Storage: from -20 to 65 °C

Humidity

· Operating: from 10% to 90% (non-condensing)

· Storage: from 5% to 95% (non-condensing)
