Interfaces

• WAN port 10/100 / 1000BASE-TX

• 4-port LAN 10/100 / 1000BASE-TX

• USB 2.0 port

Indicators

• POWER

• STATUS

• WAN

• 4 LAN indicator

• WLAN

Button

• ON / OFF button to power on / off

• RESET button to return to the factory default settings

• WPS button to establish a secure wireless connection and enable / disable the wireless network

Antenna

• Two non-removable external antenna with a gain of 2 dBi for 2.4 GHz and 3 dBi for 5 GHz

Power connector

• Connector for power supply (DC)

WAN connection types

• LTE

• 3G

• PPPoE

• IPv6 PPPoE

• PPPoE Dual Stack

• Static IP / Dynamic IP

• Static IPv6 / IPv6 Dynamic

• PPPoE + Static IP

• PPPoE + Dynamic IP

• PPTP / L2TP + Static IP

• PPTP / L2TP + Dynamic IP

Network Functions

• Supports IEEE 802.1X standard for connecting to the Internet

• DHCP-server / relay

• DHCPv6-server (Stateful / Stateless), IPv6 prefix delegation

• DNS relay

• Support Class AAAA records DNSv6

• Dynamic DNS

• Static IP-routing

• Static IPv6-routing

• IGMP Proxy

• RIP

• Supports UPnP IGD

• VLAN support

• Flow control (flow control)

• Supports ping from the external network (WAN ping respond)

• Support for SIP

• Support for RTSP

Firewall Features

• Network Address Translation (NAT)

• Stateful Packet Inspection (SPI)

• IP-filters

• IPv6-filters

• MAC-filter

• URL-filter

• DMZ-zone

• The protection ARP- and DDoS-attacks

• Virtual Servers

• Built-in content filtering service Yandeks.DNS

VPN

• IPSec / PPTP / L2TP / PPPoE pass-through

• VPN-tunnels (PPPoE, PPTP, L2TP)

• IPSec-tunnel

Function USB-interface

• USB-modem

   Automatic connection to available type of supported network (4G / 3G / 2G) 2

   Enable / disable PIN-code verification, change PIN-koda3

• USB-drive

   Print Server

   Built-in Samba server

   Built-in FTP-server

   Built-in DLNA-server

   Built-torrent-client Transmission, the possibility of downloading files on USB-drive with him

Management

• Local and remote access to the settings on the TELNET / WEB (HTTP / HTTPS)

• Web-based interface for configuration and management of multiple languages

• Notification of problems with connection and automatic redirection settings

• Update the router through the web-interface

• Automatic notification when a new software version

• Saving and loading configuration

• Support for remote logging

• Automatic synchronization of system time with a NTP-server and manually configure the date and time

• Ping

• Traceroute

• Client TR-069

נתונים פיזיים

• Dimensions 195 x 155 x 35 mm

• Weight 250 g

• Power Output: 12 V DC, 1.5 A

Temperature

• Operating: 0 to 40 ° C

• Storage: -20 to 65 ° C

Humidity

• Operating: 10% to 90% (non-condensing)

• Storage: 5% to 95% (non-condensing)

Supported USB-modems
