Hardware

Interfaces

• ADSL: 1 RJ-11 port

• LAN: 4 RJ-45 10/100BASE-TX Fast Ethernet ports

with auto-MDI/MDIX

• WLAN: built-in 802.11b, g, and n wireless interface

Frequency Range

• 2412 ~ 2484MHz

Wireless Data Rate

• 802.11b: 11, 5.5, 2, 1Mbps

• 802.11g: 54, 48, 36, 24, 18, 12, 9, 6Mbps

• 802.11n

◦ HT20: up to 150Mbps

◦ HT40: up to 300Mbps

Transmitter Output Power

The maximum value of the transmitter output power depends

upon the radio frequency regulations applied in your country

• 802.11b

◦ 16.5 ~ 18.5dBm

• 802.11g

◦ 13.5 ~ 16.5dBm

• 802.11n

◦ 13.5 ~ 16.5dBm

Modulation Schemes

• 802.11b: CCK (11, 5.5Mbps), DQPSK (2Mbps),

DBPSK (1Mbps), DSSS

• 802.11g: PSK/CCK, DBPSK, DQPSK, OFDM, BPSK,

QPSK, 64QAM, 16QAM

• 802.11n: PSK/CCK, DBPSK, DQPSK, OFDM, etc.

ADSL Standards

• ADSL

◦ Multi-mode, ANSI T1.413 Issue 2, ITU-T G.992.1

(G.dmt) Annex A, ITU-T G.992.2 (G.lite) Annex

A, ITU-T G.994.1 (G.hs)

• ADSL2

◦ ITU-T G.992.3 (G.dmt.bis) Annex A/L/M, ITU-T

G.992.4 (G.lite.bis) Annex A

• ADSL2+

◦ ITU-T G.992.5 Annex A/L/M

Software

WAN Connection Types

• ADSL

◦ PPPoE

◦ PPPoA

◦ IPoA

◦ Static IP

◦ Dynamic IP

◦ Bridge

• Ethernet

◦ PPPoE

◦ Static IP

◦ Dynamic IP

◦ Bridge

Wireless Network

• IEEE 802.11n standard, IEEE 802.11b/g compliant

• Support of guest wireless network

• WEP data encryption

• WPA/WPA2 security supporting TKIP, AES and

TKIP+AES

• MAC-based access to wireless network

• PIN and PBC methods of WPS

• Advanced settings

ATM/PPP Protocols

• Bridged and routed Ethernet encapsulation

• VC-based or LLC-based multiplexing

• ATM Forum UNI3.1/4.0 PVC (up to 8 PVCs)

• ATM Adaptation Layer Type 5 (AAL5)

• ITU-T I.610 OAM F4/F5 loopback

• ATM QoS

• PPP over ATM (RFC 2364)

• PPP over Ethernet (PPPoE)

• Keep-alive for PPP connections

Network Protocols and Functions

• Additional IP address for LAN interface

• Static IP routing

• NAT (Network Address Translation)

• DHCP server/client/relay

• DNS relay

• DDNS

• Support of VLAN

• IGMP proxy

• IGMP snooping

Firewall and Access Management Functions

• Network Address Translation (NAT)

• Stateful Packet Inspection (SPI)

• MAC filtering based on time of day and day of week

• URL filter

• Packet filtering (IP/ICMP/TCP/UDP)

• Virtual servers

• Prevention of DoS attacks

• Intrusion detection system

• DMZ

• Port Triggering

QoS

• Interface grouping

• VLAN priority (802.1p)

Configuration and Management

• Multilingual web-based interface for configuration and

management

• Access via TELNET

• Firmware update via web-based interface

• Saving/restoring configuration to/from file

• Support of remote logging

• Automatic synchronization of system time with NTP

server and manual time/date setup

Physical and Environmental

LEDs

• Power

• DSL

• Internet

• WLAN

• LAN 1-4

• WPS

Power

• External power adapter DC 12V/0.5A

Buttons

• ON/OFF power switch

• Reset to Factory Defaults button

• WPS/WLAN button

Operating Temperature

• From 0 to 40 °C (from 32 to 104 °F)

Storage Temperature

• From -20 to 70 °C (from -4 to 158 °F)

Humidity

• From 5% to 95% non-condensing
