Hardware

Processor

• RTL8685S

RAM

• 32 MB, SDRAM

Flash

• 8 MB, SPI

Interfaces

• RJ-11 DSL port

• 4 10/100BASE-TX LAN ports

LEDs

• POWER

• DSL

• INTERNET

• WLAN

• 4 LAN LEDs

• WPS

Buttons

• ON/OFF button to power on/power off

• RESET button to restore factory default settings

• WPS button to set up secure wireless connection

• WLAN button to enable/disable wireless network

Antenna

• Two internal omnidirectional antennas (2dBi gain)

MIMO

• 2 x 2

Power connector

• Power input connector (DC)

DSL Parameters

VDSL/ADSL Standards

• VDSL2: ITU G.993.2, support of 8a, 8b, 8c, 8d, 12a, 12b, 17a, 30a profiles

• ADSL: Multi-mode, ANSI T1.413 Issue 2, ITU-T G.992.1 (G.dmt) Annex A, ITU-T G.992.2 (G.lite) Annex A, ITU-T G.994.1 (G.hs)

• ADSL2: ITU-T G.992.3 (G.dmt.bis) Annex A/L/M, ITU-T G.992.4 (G.lite.bis) Annex A

• ADSL2+: ITU-T G.992.5 Annex A/L/M

ATM/PPP Protocols

• Bridged and routed Ethernet encapsulation

• VC-based or LLC-based multiplexing

• ATM Forum UNI3.1/4.0 PVC (up to 8 PVCs)

• ATM Adaptation Layer Type 5 (AAL5)

• ITU-T I.610 OAM F4/F5 loopback

• ATM QoS

• PPP over ATM (RFC 2364)

• PPP over Ethernet (PPPoE)

• Keep-alive for PPP connections

Software

WAN connection types

• PPPoA

• PPPoE

• IPv6 PPPoE

• PPPoE Dual Stack

• IPoA

• Static IP / Dynamic IP

• Static IPv6 / Dynamic IPv6

• Bridge

Network functions

• DHCP server/relay

• DHCPv6 server (Stateful/Stateless), IPv6 prefix delegation

• DNS relay

• Support of DNSv6 AAAA records

• Dynamic DNS

• Static IP routing

• Static IPv6 routing

• IGMP Proxy

• IGMP snooping

• RIP

• Support of UPnP IGD

• Support of VLAN

• WAN ping respond

• Support of SIP ALG

• Support of RTSP

Firewall functions

• Network Address Translation (NAT)

• Stateful Packet Inspection (SPI)

• IP filter

• IPv6 filter

• MAC filter

• URL filter

• DMZ

• Prevention of ARP and DDoS attacks

• Virtual servers

• Built-in Yandex.DNS web content filtering service

VPN

• IPSec/PPTP/L2TP/PPPoE pass-through

QoS

• Interface grouping

• VLAN priority (802.1p)

Management

• Local and remote access to settings through TELNET/WEB (HTTP)

• Multilingual web-based interface for configuration and management

• Firmware update via web-based interface

• Automatic notification on new firmware version

• Saving/restoring configuration to/from file

• Support of remote logging

• Automatic synchronization of system time with NTP server and manual time/date setup

• Ping function

• TR-069 client

Wireless Module Parameters

Standards

• IEEE 802.11b/g/n

Frequency range

• 2400 ~ 2483.5MHz

Wireless connection security

• WEP

• WPA/WPA2 (Personal)

• МАС filter

• WPS (PBC/PIN)

Advanced functions

• WMM (Wi-Fi QoS)

• Information on connected Wi-Fi clients

• Advanced settings

Wireless connection rate

• IEEE 802.11b: 1, 2, 5.5, and 11Mbps

• IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, and 54Mbps

• IEEE 802.11n: from 6.5 to 300Mbps (from MCS0 to MCS15)

Transmitter output power

 The maximum value of the transmitter output power depends upon the radio frequency regulations applied in your country

• 802.11b (typical at room temperature 25 °C)

16dBm (+/-1dB)

 • 802.11g (typical at room temperature 25 °C)

14dBm (+/-1dB)

 • 802.11n (typical at room temperature 25 °C)

14dBm (+/-1dB)

Receiver sensitivity

• 802.11b (typical at room temperature 25 °C)

-86dBm

 • 802.11g (typical at room temperature 25 °C)

-72dBm

 • 802.11n (typical at room temperature 25 °C)

HT20 -67dBm

HT40 -65dBm

Physical Parameters

Dimensions

• 160 x 59 x 121 mm (6.3 x 2.32 x 4.76 in)

Weight

• 215 g (0.47 lb)

Operating Environment

Power

• Output: 12V DC, 1A

Temperature

• Operating: from 0 to 40 °C

• Storage: from -20 to 70 °C

Humidity

• From 5% to 95% (non-condensing)
