משלוח חינם. אספקה תוך 1-5 ימי עסקים לאחר אישור ההזמנה.
קניה
הוסף לסל
נתוני לוח
- תושבת מעבד:B360M
- ערכת שבבים:1151
- סוג לוח:m-ATX
- תמיכה במעבדים: i3 / i5 / i7
- זכרון:DDR4 2133-2666MHZ
- Audio:7.1Ch 3Ports
- חריצי זכרון:2
- SATA3:6
- M2:1
- Audio chip:Azalia Realtek ALC887
- LAN chip:Realtek 8111H Gb LAN controller
אספקה מהירה
שרות מקצועי
אחריות יבואן רשמי
אתר מאובטח SSL
אחריות 3 שנים על ידי היבואן הרשמי.
CPU
- Supports 8th Gen Intel® Core™ processors, and Intel® Pentium® Gold and Celeron® processors for Socket LGA1151
Chipset
- Intel® B360 Chipset
Main Memory
- 2 x DDR4 memory slots, support up to 32GB
- Supports DDR4 2666/ 2400/ 2133 MHz
- Dual channel memory architecture
- Supports non-ECC, un-buffered memory
- Supports Intel® Extreme Memory Profile
Slots
- 1 x PCIe 3.0 x16 slot
- 2 x PCIe 3.0 x1 slots
Onboard Graphics
- 1 x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz
- 1 x HDMI™ port, supports a maximum resolution of 4096x2160@30Hz, 2560x1600@60Hz
STORAGE
- Intel® B360 Chipset
- 6 x SATA 6Gb/s ports
- 1 x M.2 slot (Key M)
- Supports up to PCIe 3.0 x4 and SATA 6Gb/s
- Supports 2242/ 2260/ 2280 storage devices
- Intel® Optane™ Memory Ready1
USB
- Intel® B360 Chipset
- 6x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal USB connector)
- 6x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connectors)
Audio
- Realtek® ALC887 Codec
- 7.1-Channel High Definition Audio
LAN
- 1 x RTL8111H Gigabit LAN controller
Back Panel I/O Ports
- PS/2 Combo Port
- VGA Port
- HDMI Port
- USB 3.1 Gen1
- LAN Port
- HD Audio Connectors
- USB 2.0 Port
- USB 3.1 Gen1
- MSI B360M PRO-VH back panel ports
Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 1 x USB 3.1 Gen1 connector1 (supports additional 2 USB 3.1 Gen1 ports)
- 6 x SATA 6Gb/s connectors
- 1 x Clear CMOS jumper
- 2 x Front panel connectors
- 1 x Serial port connector
- 1 x Chassis Intrusion connector
- 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
- 1 x Front panel audio connector
- 1 x 4-pin CPU fan connector
- 1 x 4-pin system fan connector
Dimension
- 22.6 cm x 18.5 cm
- m-ATX Form Factor
Mounting
- 6 mounting holes
OPERATING SYSTEM
- Support for Windows® 10 64-bit
