נתוני לוח
- תושבת מעבד:B360M
- ערכת שבבים:1151
- סוג לוח:m-ATX
- תמיכה במעבדים: i3 / i5 / i7
- זכרון:DDR4 2133-2666MHZ
- Audio:7.1Ch 6Ports
- חריצי זכרון:4
- SATA3:4
- M2:2
- Audio chip:Realtek ALC892
- LAN chip:Intel I219-V
אספקה מהירה
שרות מקצועי
אחריות יבואן רשמי
אתר מאובטח SSL
אחריות 3 שנים על ידי היבואן הרשמי.
CPU
- Supports 8th Generation Intel® Core™ Processors, and Intel® Pentium® Gold and Celeron® Processors for Socket LGA1151
Chipset
- Intel® B360 Chipset
Main Memory
- 4 x DDR4 memory slots, support up to 64GB
- Supports DDR4 2666/ 2400/ 2133 MHz
- Dual channel memory architecture
- Supports non-ECC UDIMM memorye
- Supports Intel® Extreme Memory Profile
Slots
- 2 x PCIe 3.0 x16 slots (support x16/x4 modes)
- 2 x PCIe 3.0 x1 slots
Onboard Graphics
- 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
- 1 x DisplayPort port 1.2, supports a maximum resolution of 4096X2304@60Hz
- 1 x HDMI™ port 1.4, supports a maximum resolution of 4096x2160@30Hz
STORAGE
- Intel® B360 Chipset
- 4 x SATA 6Gb/s ports
- 2 x M.2 slots (Key M)
- M2_1 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices1
- M2_2 supports up to PCIe 3.0 x4, 2242/ 2260/ 2280 storage devices2
- Intel® Optane™ Memory Ready ,supported on M2_23
USB
- Intel® B360 Chipset
- 3 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-C and 1 Type-A ports on the back panel, 1 Type-C internal connector)
- 2 x USB 3.1 Gen1 (SuperSpeed USB) ports available through the internal USB connector
- 6 x USB 2.0 (High-speed USB) ports (4 Type-A ports on the back panel, 2 ports available through the internal USB connector)
Audio
- Dual Realtek® ALC892 Codec
- 7.1-Channel High Definition Audio
- Supports S/PDIF output
LAN
- 1 x Intel I219-V Gigabit LAN controller
Back Panel I/O Ports
- PS/2 Combo Port
- DisplayPort
- LAN Port
- USB 3.1 Gen2 Type A
- HD Audio Connectors
- USB 2.0 Port
- DVI-D Port
- HDMI Port
- USB 2.0 Port
- USB 3.1 Gen2 Type C
- Optical S/PDIF OUT
Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 4 x SATA 6Gb/s connectors
- 1 x USB 3.1 Gen2 Type-C port
- 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
- 1 x USB 2.0 connector (supports additional 2 USB 2.0 ports)
- 1 x 4-pin CPU fan connector
- 3 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x 5050 RGB LED strip 12V connector
- 1 x Thunderbolt add-on card connector
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Clear CMOS jumper
Dimension
- 24.3 cm x 24.3
- Micro-ATX Form Factor
Mounting
- 8 mounting holes
OPERATING SYSTEM
- Support for Windows® 10 64-bit
