נתוני לוח
- תושבת מעבד:B360
- ערכת שבבים:1151
- סוג לוח:ATX
- תמיכה במעבדים: i3 / i5 / i7
- זכרון:DDR4 2133-2666MHZ
- Audio:7.1Ch 6Ports
- חריצי זכרון:4
- SATA3:6
- M2:2
- Audio chip:Azalia Realtek ALC1220
- LAN chip:Intel I219-V
אספקה מהירה
שרות מקצועי
אחריות יבואן רשמי
אתר מאובטח SSL
אחריות 3 שנים על ידי היבואן הרשמי.
CPU
- Supports 8th Generation Intel® Core™ Processors, and Intel® Pentium® Gold and Celeron® Processors for Socket LGA1151
Chipset
- Intel® B360 Chipset
Main Memory
- 4 x DDR4 memory slots, support up to 64GB
- Supports DDR4 2666/ 2400/ 2133 MHz1
- Dual channel memory architecture
- Supports non-ECC UDIMM memorye
- Supports Intel® Extreme Memory Profile
Slots
- 2 x PCIe 3.0 x16 slots (support x16/x4 modes)1
- 3 x PCIe 3.0 x1 slots
Onboard Graphics
- 1 x HDMI™ port 1.4, supports a maximum resolution of 4096x2160@30Hz
- 1 x DisplayPort port 1.2, supports a maximum resolution of 4096X2304@60Hz
- MULTI-GPU
- Supports 2-Way AMD® CrossFire™ Technology
STORAGE
- Intel® B360 Chipset
- 6 x SATA 6Gb/s ports*1
- 2 x M.2 slots (Key M)
- M2_1 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices2
- M2_2 supports up to PCIe 3.0 x4, 2242/ 2260/ 2280 storage devices
- Intel® Optane™ Memory Ready for the M2_2 slot only
- SATA2 port will be unavailable when an M.2 SATA SSD module has been installed in the M2_1 slot.Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.
USB
- Intel® B360 Chipset
- 3 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports
- (1 Type-A port and 1 Type-C port on the back panel, 1 Type-C port available through the internal USB connector)
- 2 x USB 3.1 Gen1 (SuperSpeed USB) ports available through the internal USB connector
- 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
- ASMedia® ASM1074
- 4 x USB 3.1 Gen1 (SuperSpeed USB) Type-A ports on the back panel
Audio
- Realtek® ALC1220 Codec
- 7.1-Channel High Definition Audio
- Supports S/PDIF output
LAN
- 1 x Intel® I219-V Gigabit LAN controller
Back Panel I/O Ports
- PS/2 Combo Port
- USB 3.1 Gen1
- LAN Port
- HD Audio Connectors
- USB 2.0 Port
- DisplayPort
- USB 3.1 Gen2 Type A + C
- HDMI Port
- USB 3.1 Gen1
- Optical S/PDIF OUT
Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 6 x SATA 6Gb/s connectors
- 1 x USB 3.1 Gen 2 Type-C connector
- 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
- 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
- 1 x 4-pin CPU fan connector
- 1 x 4-pin water pump fan connector
- 5 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x 5050 RGB LED strip 12V connector (JRGB1)
- 1 x WS2812B Individually Addressable RGB LED strip 5V connector (JRAINBOW1)
- 1 x CORSAIR connector (JCORSAIR1)
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Clear CMOS jumper
Dimension
- 30.4 cm x 24.3 cm
- ATX Form Factor
Mounting
- 9 mounting holes
OPERATING SYSTEM
- Support for Windows® 10 64-bit
