נתוני לוח
- תושבת מעבד:H370M
- ערכת שבבים:1151
- סוג לוח:m-ATX
- תמיכה במעבדים: i3 / i5 / i7
- זכרון:DDR4 2133-2666MHZ
- Audio:7.1Ch 3Ports
- חריצי זכרון:4
- SATA3:6
- M2:2
- Audio chip:Azalia Realtek ALC887
- LAN chip:Realtek 8111H Gb LAN controller
אספקה מהירה
שרות מקצועי
אחריות יבואן רשמי
אתר מאובטח SSL
אחריות 3 שנים על ידי היבואן הרשמי.
CPU
- Supports 8th Generation Intel® Core™ Processors, and Intel® Pentium® Gold and Celeron® Processors for Socket LGA1151
Chipset
- Intel® H370 Chipset
Main Memory
- 4 x DDR4 memory slots, support up to 64GB
- Supports DDR4 2666/ 2400/ 2133 MHz1
- Dual channel memory architecture
- Supports non-ECC UDIMM memorye
- Supports Intel® Extreme Memory Profile
Slots
- 1 x PCIe 3.0 x16 slot
- 2 x PCIe 3.0 x1 slots
Onboard Graphics
- 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
- 1 x HDMI™ port 1.4, supports a maximum resolution of 4096x2160@30Hz
STORAGE
- Intel® H370 Chipset
- 6 x SATA 6Gb/s ports1
- 1 x M.2 slots (Key M)
- Support up to PCIe 3.0 x4 and SATA 6Gb/s
- Supports 2242/ 2260 /2280/ 22110 storage devices
- Intel® Optane™ Memory Ready2
- The SATA1 connector will be unavailable when a SATA M.2 SSD has been installed in the M.2_1 slot.Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.
RAID
- Intel® H370 Chipset
- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
USB
- Intel® H370 Chipset
- 6 x USB 3.1 Gen1 (SuperSpeed USB) ports (3 Type-A & 1 Type-C ports on the back panel, 2 ports available through the internal USB connector)
- 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
Audio
- Dual Realtek® ALC887 Codec
- 7.1-Channel High Definition Audio
LAN
- 1 x Realtek 8111H Gigabit LAN controller
Back Panel I/O Ports
- Mouse and Keyboard Port
- LAN Port
- USB 3.1 Gen1 Type A
- HD Audio Connectors
- DVI-D Port
- HDMI Port
- USB 2.0 Port
- USB 3.1 Gen1 Type C
Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 6 x SATA 6Gb/s connectors
- 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
- 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
- 1 x 4-pin CPU fan connector
- 2 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 1 x Parallel port connector
- 1 x Serial port connector
- 2 x Front panel connectors
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Thunderbolt add-on card connector
- 1 x RGB LED connector
- 1 x Clear CMOS jumper
Dimension
- 24.4 cm x 24.4 cm
- m-ATX Form Factor
Mounting
- 8 mounting holes
OPERATING SYSTEM
- Support for Windows® 10 64-bit
