משלוח חינם. אספקה תוך 1-5 ימי עסקים לאחר אישור ההזמנה.
קניה
הוסף לסל
נתוני לוח
- תושבת מעבד:Z370
- ערכת שבבים:1151
- סוג לוח:ATX
- תמיכה במעבדים: i3 / i5 / i7
- זכרון:DDR4 2133-4000+(OC)
- Audio:7.1Ch 6Ports
- חריצי זכרון:4
- SATA3:6
- M2:2
- Audio chip:Realtek ALC892
- LAN chip:Intel I219-V
אספקה מהירה
שרות מקצועי
אחריות יבואן רשמי
אתר מאובטח SSL
אחריות 3 שנים על ידי היבואן הרשמי.
CPU
- Supports 8th Gen Intel® Core™ processors, and Intel® Pentium® and Celeron® processors for Socket LGA1151
Chipset
- Intel® Z370 Chipset
Main Memory
- 4 x DDR4 memory slots, support up to 64GB
- Supports DDR4 4000+(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC)/ 2800(OC)/ 2667/ 2400/ 2133 MHz Memory
- Dual channel memory architecture
- Supports non-ECC, un-buffered memory
- Supports Intel® Extreme Memory Profile
Slots
- 3 x PCIe 3.0 x16 slots (support x16/x4/x1 modes)1
- 3 x PCIe 3.0 x1 slots2
- The PCI_E4 slot will be unavailable when an M.2 PCIe SSD module has been installed in the M.2_2 slot.The PCI_E2 slot will be unavailable when an expansion card has been installed in the PCI_E3 slot.
Onboard Graphics
- 1 x HDMI™ port, supports a maximum resolution of 4096x2160@24Hz
- 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
- MULTI-GPU
- Supports 2-Way AMD® CrossFire™ Technology
STORAGE
- Intel® Z370 Chipset
- 6 x SATA 6Gb/s ports1
- 2 x M.2 slots (Key M)
- Support up to PCIe 3.0 x4 and SATA 6Gb/s
- Support PCIe 3.0 x4 NVMe U.2 SSD with Turbo U.2 Host Card2
- M2_1 slot supports 2242/ 2260 /2280/ 22110 storage devices
- M2_2 slot supports 2242/ 2260 /2280 storage devices2
- Intel® Optane™ Memory Ready for all M.23
- Supports Intel® Smart Response Technology for Intel Core™ processors
- M.2 and SATA ports maximum support 2x M.2 PCIe SSDs + 6x SATA HDDs. Please refer to manual for more detail.The Turbo U.2 Host Card is not included, please purchase separately.Please refer to manual for Intel® Optane™ Memory Configuration.
RAID
- Intel® Z370 Chipset
- Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA storage devices
- Supports RAID 0 and RAID1 for M.2 PCIe storage devices1
- M.2 PCIe RAID volume can be created with M.2/Optane Genie, Please refer to manual for more detail.
USB
- ASMedia® ASM3142 Chipset
- 1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-C port on the back panel
- 1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-A port on the back panel
- Intel® Z270 Chipset
- 8 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
- 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
Audio
- Realtek® ALC892 Codec
- 7.1-Channel High Definition Audio
- Supports S/PDIF output
LAN
- 1 x Intel® I219-V Gigabit LAN controller
Back Panel I/O Ports
- PS/2 GAMING Device Port
- USB 3.1 Gen1
- Intel® Gigabit LAN Port
- Golden Audio Connectors
- USB 2.0 Ports
- DVI-D Port
- USB 3.1 Gen2
- HDMI
- Optical S/PDIF-Out
- MSI z370 tomahawk back panel ports
Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 6 x SATA 6Gb/s connectors
- 2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
- 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
- 1 x 4-pin CPU fan connector
- 1 x 4-pin water pump fan connector
- 4 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x RGB LED connector
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Serial port connector
- 1 x Clear CMOS jumper
Dimension
- 30.4 cm x 24.3 cm
- ATX Form Factor
Mounting
- 9 mounting holes
OPERATING SYSTEM
- Support for Windows® 10 64-bit
