נתוני לוח
- תושבת מעבד:X299
- ערכת שבבים:2066
- סוג לוח:ATX
- תמיכה במעבדים: i7
- זכרון:DDR4 Quad 2133-4266+OC
- Audio:7.1Ch 5Ports
- חריצי זכרון:8
- SATA3:8
- M2:2xM.2+1xU.2
- Audio chip:Realtek ALC1220
- LAN chip:Intel I219-V
אספקה מהירה
שרות מקצועי
אחריות יבואן רשמי
אתר מאובטח SSL
אחריות 3 שנים על ידי היבואן הרשמי.
CPU
- Supports Intel® Core™ X-Series Processor Family for LGA2066 Socket
Chipset
- Intel® X299 Chipset
Main Memory
- Intel® Core™ X-series Processors (6-core above CPU 78XX/79XX)
- 8 x DDR4 memory slots, support up to 128GB
- Quad channel memory architecture with the CPU that supports up to 4-channels DDR41
- X-series processor support DDR4 4133+(OC) /4000(OC) /3866(OC) /3800(OC) /3733(OC) /3600(OC) /3466(OC) /3400(OC) /3333(OC) /3200(OC) /3000(OC) /2933(OC) /2800(OC)/2667/2400/2133 MHz2
- Intel® Core™ X-series Processors (4 core CPU i7-7740X/i5-7640X)
- 4 x DDR4 memory slots, support up to 64GB
- Dual channel memory architecture with the CPU that supports up to 2-channels DDR41
- X-series processor support DDR4 4500+(OC)/4400(OC) /4333(OC) /4266(OC) /4200(OC) /4133(OC) /4000(OC) /3866(OC) /3800(OC) /3733(OC) /3600(OC) /3466(OC) /3400(OC) /3333(OC) /3200(OC) /3000(OC) /2933(OC) /2800(OC)/2667/2400/2133 MHz2
- Supports Intel® Extreme Memory Profile.
Slots
- 4 x PCIe 3.0 x16 slots
- Support x16/x16/x8 mode with the 44-lane CPU.
- Support x16/x8/x4 modes with the 28-lane CPU.
- Support x8/x8/x0, x8/x4/x4 modes with the 16-lane CPU.
- 1 x PCIe 3.0 x1 slots
MULTI-GPU
- Supports NVIDIA® SLI™ Technology
- Supports AMD® CrossFire™ Technology
STORAGE
- Intel® X299 Chipset
- 8 x SATA 6Gb/s ports1
- 2 x M.2 slot (Key M)
- Supports up to PCIe 3.0 x4 and SATA 6Gb/s
- M2_1 slot supports 2242/ 2260 /2280 storage devices
- M2_2 slot supports 2242/ 2260 /2280/ 22110 storage devices
- Supports Intel® Optane™ Memory Ready for all M.2 slots2
- 1 x U.2 port3
- Supports PCIe 3.0 x4 NVMe storage
- Supports Intel® Smart Response Technology4
- M.2 slots and SATA ports share the same bandwidth. Please refer to user manual for U.2, M.2 & SATA combination table.Please refer to user manual for Intel® Optane™ Memory Configuration.PCI_E2 shares bandwidth with U2_1. If you install a PCE_E2 device, the U2_1 will be disabled.The functions will be supported depend on the CPU.
RAID
- Intel® X299 Chipset
- Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA storage devices
- Supports RAID 0 and RAID1 for M.2 PCIe storage devices1
- M.2 PCIe RAID volume can be created with M.2/Optane Genie. Please refer to user manual for Creating a M.2 PCIe SSD RAID with M.2/Optane Genie.
USB
- Intel® X299 Chipset
- 8 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
- 5 x USB 2.0 (High-speed USB) ports (4 Type-A ports on the back panel, 1 port available through the internal USB connector)
- ASMedia® ASM3142 Chipset
- 2 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-A port and 1 Type-C port on the back panel)
- 1 x USB 3.1 Gen2 Type-C port internal USB connector
- USB 2.0 Hub GL850G
- 3 x USB 2.0 (High-speed USB) ports available through the internal USB connectors.
Audio
- Realtek® ALC1220 Codec
- 7.1-Channel High Definition Audio
- Supports S/PDIF output
LAN
- 1 x Intel® I219-V Gigabit LAN controller
Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 8 x SATA 6Gb/s connectors
- 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
- 2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
- 1 x USB 3.1 Gen2 Type-C port
- 1 x 4-pin CPU fan connector
- 1 x 4-pin Water Pump connector
- 4 x 4-pin system fan connectors
- 2 x Front panel connectors
- 1 x Front panel audio connector
- 1 x LED extension connector
- 1 x TPM module connector
- 1 x Virtual RAID on CPU connector
- 1 x Thunderbolt add-on card connector
Back Panel I/O Ports
- Keyboard / Mouse
- Clear CMOS Button
- USB 3.1 Gen1
- Intel® Gigabit LAN
- Golden Audio Connectors
- USB 2.0
- USB 3.1 Gen2 Type-A/C
- Optical S/PDIF-Out
Dimension
- 30.5 cm x 24.3 cm
- ATX Form Factor
Mounting
- 9 mounting holes
