נתוני לוח
- תושבת מעבד:X299
- ערכת שבבים:2066
- סוג לוח:ATX
- תמיכה במעבדים:I7
- זכרון:DDR4 Quad 2133-4266+OC
- Audio:7.1Ch 5Ports
- חריצי זכרון:8
- SATA3:8
- M2:2xM.2+1xU.2
- Audio chip:Realtek ALC1220
- LAN chip:Intel I219-V + Intel WIFI+BT
אספקה מהירה
שרות מקצועי
אחריות יבואן רשמי
אתר מאובטח SSL
אחריות 3 שנים על ידי היבואן הרשמי.
CPU
- Supports Intel®Core™ X-Series Processor Family for LGA2066 Socket
Chipset
- Intel® X299 Chipset
Main Memory
- Intel® Core™ X-series Processors (6-core above CPU 78XX/79XX)
- 8 x DDR4 memory slots, support up to 128GB1
- Quad channel memory architecture with the CPU that supports up to 4-channels DDR42
- X-series processor support DDR4 4133+(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/ 3400(OC)/3333(OC)/3200(OC)/ 3000(OC)/2933(OC)/2800(OC)/ 2667/2400/2133 MHz1
- Intel® Core™ X-series Processors (4 core CPU i7-7740X/i5-7640X)
- 4 x DDR4 memory slots, support up to 64GB1
- Dual channel memory architecture with the CPU that supports up to 2-channels DDR42
- X-series processor support DDR4 4500+(OC)/4400(OC)/ 4333(OC)/4266(OC)/4200(OC)/ 4133(OC)/4000(OC)/ 3866(OC)/ 3800(OC)/3733(OC)/3600(OC)/ 3466(OC)/3400(OC)/ 3333(OC)/3200(OC)/3000(OC)/ 2933(OC)/2800(OC)/ 2667/2400/2133 MHz1
- Supports Intel® Extreme Memory Profile
Slots
- 4 x PCIe 3.0 x16 slots
- Support x16/ x4*/ x16/ x8 mode with the 44-lane CPU.1
- Support x16/ x4*/ x8/ x4 modes with the 28-lane CPU.1
- Support x8/ x4*/ x8/ x0, x8/ x4*/ x4/ x4 modes with the 16-lane CPU.1
- 2 x PCIe 3.0 x1 slots
- The PCI_E3 lanes are supported by PCH.
MULTI-GPU
- Supports 3-Way NVIDIA® SLI™ Technology
- Supports 3-Way AMD CrossFire™ Technology
STORAGE
- Intel® X299 Chipset
- 8 x SATA 6Gb/s ports1
- 2 x M.2 slots (Key M)1
- Supports up to PCIe 3.0 x4 and SATA 6Gb/s
- M2_1 slot supports 2242/ 2260 /2280 storage devices
- M2_2 slot supports 2242/ 2260 /2280/ 22110 storage devices
- Intel® Optane™ Memory Ready2
- 1 x U.2 port1
- Supports PCIe 3.0 x4 NVMe storage
- Supports Intel® Smart Response Technology
- PCI_E3 slot, M.2 slots, U.2 port and SATA ports share the same bandwidth. Please refer to manual for PCI_E3/ U.2/ M.2/ SATA Combination table.Please refer to manual for Intel® Optane™ Memory Configuration.
RAID
- Intel® X299 Chipset
- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
- Supports RAID 0 and RAID 1 for M.2 storage devices1
- M.2 PCIe RAID volume can be created with M.2/Optane Genie. Please refer to manual for M.2 PCIe SSD RAID.
USB
- ASMedia® ASM3142 Chipset
- 1 x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) Type-A port on the back panel
- 2 x USB 3.1 Gen2 (Super Speed USB 10Gbps) Type-C ports(1 port on the back panel, 1 port available through the internal USB connector)
- ASMedia® ASM1074 Hub
- 3 x USB 3.1 Gen1 (SuperSpeed USB) Type-A ports on theback panel
- Intel® X299 Chipset
- 5 x USB 3.1 Gen1 (SuperSpeed USB) ports (1 port on the back panel, 4 ports available through the internal USB connectors)
- 7 x USB 2.0 (High-speed USB) ports (3 ports on the back panel, 4 ports available through the internal USB connectors)
- WIRSLESS LAN & BLUETOOTH®
- Intel® Dual Band Wireless-AC 8265 module (optional)
- The Wireless module is pre-install in the M2_3 (Key-E) slot.
- Supports Wi-Fi 802.11 a/b/g/n/ac, dual band (2.4GHz, 5GHz) up to 867 Mbps speed.
- Supports Dual Mode Bluetooth® 2.1, 2.1+EDR, 3.0, 4.0, BLE, 4.2
Audio
- Dual Realtek® ALC1220 Codec
- 7.1-Channel High Definition Audio
- Supports S/PDIF output
LAN
- 1 x Intel® I219-V Gigabit LAN controller
Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 1 x 4-pin ATX 12V power connector
- 8 x SATA 6Gb/s connectors
- 3 x M.2 slots (Key M x2, Key E x1)
- 1 x U.2 port
- 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
- 2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
- 1 x USB 3.1 Gen2 Type-C port
- 1 x 4-pin CPU fan connector
- 1 x 4-pin Water Pump connector
- 4 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Clear CMOS jumper
- 1 x Power button
- 1 x Reset button
- 1 x Multi-BIOS switch
- 1 x RGB LED connector
- 1 x Virtual RAID on CPU connector
- 1 x Thunderbolt Add-on Card Connector
Back Panel I/O Ports
- Clear CMOS Button
- Keyboard / Mouse
- Intel Wi-Fi & Bluetooth
- Intel® Gigabit LAN
- Golden Audio Connectors
- BIOS Flashback Button
- USB 2.0
- USB 2.0 / BIOS Flashback+
- USB 3.1 Gen1
- USB 3.1 Gen2 Type-A/C
- Optical S/PDIF-Out
Dimension
- 30.5 cm x 24.3 cm
- ATX Form Factor
Mounting
- 9 mounting holes
