משלוח חינם. אספקה תוך 1-5 ימי עסקים לאחר אישור ההזמנה.
קניה
הוסף לסל
נתוני לוח
- תושבת מעבד:A320
- ערכת שבבים:AM4
- סוג לוח:m-ATX
- תמיכה במעבדים:RYZEN
- זכרון:DDR4 1866-3200+(OC)
- Audio:7.1Ch 3Ports
- חריצי זכרון:2
- SATA3:4
- M2:N/A
- Audio chip:Azalia Realtek ALC887
- LAN chip:Realtek 8111H Gb LAN controller
אספקה מהירה
שרות מקצועי
אחריות יבואן רשמי
אתר מאובטח SSL
אחריות 3 שנים על ידי היבואן הרשמי.
CPU
- Supports AMD® Ryzen™ 1st and 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics Processors and AMD® A-series / Athlon™ Processors for Socket AM4
Chipset
- AMD® A320 Chipset
Main Memory
- 2 x DDR4 memory slots, support up to 32GB
- Support DDR4 1866/2133/2400/2667/2933(OC)/3200(OC) Mhz*
- Dual channel memory architecture
- Supports ECC UDIMM memory (non-ECC mode)
- Support non-ECC UDIMM memory
- * 7th Gen A-series/ Athlon processors support a maximum of DDR4 2400 Mhz.
- * Please refer www.msi.com for more information on compatible memory
Slots
- 1 x PCIe 3.0 x16 slots
- - RYZEN series processors support x16 mode
- - 7th Gen A-series/ Athlon™ processors support x8 mode
- 2 x PCIe 3.0 x1 slots
Onboard Graphics
- 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz
- 1 x VGA port, supports a maximum resolution of 2048x1280@60Hz, 1920x1200@60Hz
- * Only support when using Ryzen™ Desktop Processors with Radeon Vega Graphics A-Series/ Athlon™ Processors
- * Maximum shared memory of 2048 MB
On-Board SATA
- 4 x SATA 6Gb/s ports
- Supports RAID 0, RAID1 and RAID 10
USB
- -6 x USB 3.1 Gen1 (SuperSpeed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connector)
- - 6 x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connector)
Audio
- Realtek® ALC887 Codec
- 7.1-Channel High Definition Audio
LAN
- 1 x RTL8111H Gigabit LAN controller
Internal I/O Connectors
- - 1 x 24-pin ATX main power connector
- - 1 x 8-pin ATX 12V power connector
- - 4 x SATA 6Gb/s connectors
- - 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
- - 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
- - 1 x 4-pin CPU fan connector
- - 1 x 4-pin system fan connector
- - 1 x Front panel audio connector
- - 2 x Front panel connectors
- - 1 x TPM module connector
- - 1 x Chassis Intrusion connector
- - 1 x Serial port connector
- - 1 x Clear CMOS jumper
Back Panel I/O Ports
- - 1 x PS/2 keyborard/ mouse combo port
- - 2 x USB 2.0 Type-A ports
- - 1 x DVI-D port
- - 1 x VGA port
- - 1 x LAN (RJ45) port
- - 4 x USB 3.1 Gen1 Type-A ports
- - 3 x audio jacks
Dimension
- 24.4 cm x 20.6 cm
- m-ATX Form Factor
Mounting
- 6 mounting holes
OPERATING SYSTEM
- Support for Windows® 10 64-bit
- Support for Windows® 7 64-bit
- * To support Windows® 7 64-bit, you must install an AMD Pinnacle Ridge Summit Ridge CPU.
