נתוני לוח
- תושבת מעבד:B350
- ערכת שבבים:AM4
- סוג לוח:m-ATX
- תמיכה במעבדים:RYZEN
- זכרון:DDR4 1866-3200+(OC)
- Audio:7.1Ch 6Ports
- חריצי זכרון:4
- SATA3:4
- M2:1
- Audio chip:Realtek ALC892
- LAN chip:Realtek 8111H Gb LAN controller
אספקה מהירה
שרות מקצועי
אחריות יבואן רשמי
אתר מאובטח SSL
אחריות 3 שנים על ידי היבואן הרשמי.
CPU
- Supports AMD® Ryzen™ 1st and 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics Processors and AMD® A-series / Athlon™ Processors for Socket AM4
Chipset
- AMD® B350 Chipset
Main Memory
- 4 x DDR4 memory slots, support up to 64GB
- - Supports DDR4 1866/ 2133/ 2400/ 2667(OC)/ 2933(OC)/ 3200(OC)+ Mhz *
- Dual channel memory architecture
- Supports non-ECC UDIMM memory
- Supports ECC UDIMM memory (non-ECC mode)
- * 7th Gen A-series/ Athlon ™ processors support a maximum of 2400 MHz. Please refer www.msi.com for more information on compatible memory.
Slots
- 1 x PCIe 3.0 x16 slot
- - RYZEN series processors support x16 mode
- - 7th Gen A-series/ Athlon™ processors support x8 mode
- 1 x PCIe 2.0 x16 slot (supports x4 mode)
- 2 x PCIe 2.0 x1 slots*
Onboard Graphics
- 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz*
- 1 x HDMI™ 1.4 port, supports a maximum resolution of 4096x2160@24Hz*
- 1 x DisplayPort, supports a maximum resolution of 4096x2160@60Hz*
- * Only support when using Ryzen™ Desktop Processors with Radeon Vega Graphics A-Series/ Athlon™ Processors
- * Maximum shared memory of 2048 MB
- Multi-GPU
- Supports 2-Way AMD® CrossFire™ Technology
- - RYZEN series processors support x16/x4 mode
- - 7th Gen A-series/ Athlon™ processors support x8/x4 mode
STORAGE
- AMD® B350 Chipset
- 4 x SATA 6Gb/s ports*
- 1 x M.2 slot (Key M)
- - M2_1 slot supports PCIe 3.0 x4 (RYZEN series processor) or PCIe 3.0 x2 (7th Gen A-series/ Athlon™ processors) and SATA 6Gb/s 2242/ 2260 /2280 storage devices
RAID
- AMD®B350 Chipset
- - Supports RAID 0, RAID1 and RAID 10
USB
- AMD® B350 Chipset
- - 4 x USB 3.1 Gen1 (SuperSpeed USB) ports available through the internal USB connector
- - 6 x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
- AMD® CPU - 4 x USB 3.1 Gen1 (SuperSpeed USB) ports (3 Type-A and 1 Type-C ports on the back panel)
Audio
- Realtek® ALC892 Codec
- - 7.1-Channel High Definition Audio
LAN
- 1 x Realtek® 8111H Gigabit LAN controller
Internal I/O Connectors
- - 1 x 24-pin ATX 12V power connector
- - 1 x 8-pin ATX 12V power connector
- - 4 x SATA 6Gb/s connectors
- - 2 x USB 2.0 connectors (support additional 4 USB 2.0 ports)
- - 2 x USB 3.1 Gen1 connectors (support additional 4 USB 3.1 Gen1 ports)
- - 1 x 4-pin CPU fan connector
- - 3 x 4-pin system fan connectors
- - 1 x RGB LED connector
- - 1 x TPM module connector
- - 1 x Front panel audio connector
- - 2 x System panel connectors
- - 1 x Chassis Intrusion connector
- - 1 x Serial port connector
- - 1 x Parallel port connector
- - 1 x Clear CMOS jumper
Back Panel I/O Ports
- - 1 x PS/2 keyboard/ mouse combo port
- - 2 x USB 2.0 Type-A ports
- - 1 x DVI-D port
- - 1 x DisplayPort
- - 1 x HDMI™ port
- - 1 x LAN (RJ45) port
- - 3 x USB 3.1 Gen1 Type-A ports
- - 1 x USB 3.1 Gen1 Type-C port
- - 5 x OFC audio jacks
- - 1 x Optical S/PDIF OUT connector
Dimension
- 24.3 cm x 24.3 cm
- Micro-ATX Form Factor
Mounting
- 8 mounting holes
OPERATING SYSTEM
- Support for Windows® 10 64-bit
- Support for Windows® 7 64-bit
- * To support Windows® 7 64-bit, you must install an AMD Pinnacle Ridge And Summit Ridge CPU.
